13.3" + 37" Totem Dual Screen LCD Digital Signage Touch Kiosk Vertical Video Display Advertising Player Android Floor Standing

Interactive Floor-Standing Totem Display

All-in-One Kiosk Totem with Dual Display
Featuring a 13.3-inch adjustable touch screen on top and a 37-inch vertical non-touch display below, this all-in-one digital signage totem is ideal for any indoor public space. Equipped with dual Rockchip CPUs, built-in Wi-Fi, Bluetooth, and a cloud-based CMS. Runs on open-root Android for maximum flexibility and full customization.


Key Features:

Dual Display Configuration:
Equipped with two integrated displays — a 37" ultra-wide screen (1920×540 resolution, 32:9 aspect ratio) for dynamic horizontal content and a 13.3" Full HD screen (1920×1080, 16:9) ideal for supporting visuals or interactive menus.

Display Performance:

• Brightness: 500 cd/m² (37") and 400 cd/m² (13.3") ensure excellent visibility in indoor environments.

• Viewing Angle: 178° full-view angle (89/89/89/89 CR≥10) for consistent image quality from all directions.

• Color Depth: 16.7 million colors with 72% NTSC color gamut for vivid image reproduction.

• Contrast Ratio: 1000:1 on both screens for deep blacks and high clarity.

System & Hardware:

• Operating System: Android 11

• CPU: Dual RK566 processors (one per screen)

• Memory: 2GB RAM + 16GB ROM (per display module) for responsive performance and multimedia storage.

Connectivity & Interfaces:

• Includes dual USB ports, TF card slot, Audio out, RJ45 Ethernet, HDMI OTG, and DC IN.

• Network: Supports Ethernet connectivity; optional modules for WiFi, Bluetooth, or 4G can be integrated.

• Speakers: Built-in stereo speakers (2x) for multimedia playback or announcements.

Installation & Design:

• Form Factor: Vertical freestanding installation with a sleek, modern design.

• Dimensions: 350 × 350 × 1260 mm

• Weight: 25 kg

• Power Consumption: ≤55W

• Power Supply: AC 110–240V input, DC12V system voltage.

Durability & Application:
Designed for 24/7 commercial use in retail, hospitality, transportation hubs, and public venues. The dual-screen layout enhances visual impact, making it ideal for promotions, product highlights, or digital directories.

Specification
